Product Details
WF-8900 940W Power Center with 6 AC/11 DC Branches (WF-8955PEC-LIS) by WFCO®. The 8900 Series models provide AC and DC distribution with innovative features. They can accommodate a 30 Amp main AC circuit breaker and up to five branch circuits. Eleven-branch DC circuits are available with LED lights for each DC circuit to illuminate and identify open circuits.
Specifications:
| Amperage: 55A |
| AC Circuits: 6 AC |
| DC Circuits: 11 DC Branches |
| Output Power: 940W |
| Protection Types: Reverse Polarity, Over Current, Cooling System, Over Voltage, Over Temperature |
| Output Power: 940 W |
| Input Voltage/Hz : 105-130 VAC/60 Hz |
| Weight: 7 lb |
| Replacement Board (if applicable): WF-8955-MBA (Main Board Assembly, 55 Amps) |
| Converter Type: Three-Stage Converter Charger |
| Output Current: 55 A |
| Voltage Output: 13.2 – 14.4V DC Range |
| Absorption Mode (Nominal Voltage): 13.6V DC |
| Bulk Mode (Quick Charging Voltage): 14.4V DC |
| Float Mode (Trickle Charge Voltage): 13.2V DC |
| Over Current: Yes |
| Over Temperature: Yes |
| Over Voltage: Yes |
| Reverse Polarity: Yes |
| Cooling System: Yes |
| Size: 12-3/16″ x 10-7/8″ x 7-1/4″ |
| AC Circuits (twin breakers): 1 main and 5 branch circuits |
| DC Circuits (Quantity): (2 30A max), 11 (9 20A max) |
| Case Material: Plastic |
| Case Color: Brown |
Features:
- High quality at an affordable price
- Expertly made from premium materials
- Built to match your exact requirements
WFCO® Group has been serving the RV and Automotive Industries for over 40 years. Founded in 1976, WFCO® provides a variety of components and tools ranging from power switching components to pneumatic accessories. Since its beginning, the WFCO Group has had numerous milestones, including the establishment of the Electronics Division (WFCO Electronics) in 1999. The Electronics Division prides itself on being on the forefront of trends, with the continuous development of innovative products. This has helped WFCO Electronics become the leader in manufacturing, distribution and servicing of power conversion products in the RV industry, preferred more than 4-to-1 by RV manufacturers.
