100A Battery Latch Disconnect Switch (01-00055-002) by Intellitec®. Provide a simple, reliable, and cost effective means of remotely disconnecting the battery of larger vehicles or boats. Rather than having to install long runs of heavy, unprotected battery cable to a large cumbersome switch, the Disconnect can be located near the battery, out of normal reach.
Notes:
- Remotely Disconnect The Batteries Of An RV/ Boat To Prevent Unwanted Drain When The RV/ Boat Are Put Into Storage.
Specifications:
| Continuous Ampere Rating: 100A |
| Surge Ampere Rating: 500A |
| Activation Type: Mechanical |
| Installation Type: Bolt-On |
| Fuses: Yes |
Features:
- Latching Mechanism
- Momentary Current Draw For Actuation (Open Or Closed)
- Uses Latest Contact Material Technology
- Provides A Simple, Reliable, And Cost Effective Means Of Remotely Disconnecting The Battery Of Larger Vehicles Or Boats
- The Concern Of Long Battery Cables Shorting To The Chassis Is All But Gone
- Latching Feature Allows The Disconnect To Operate Without Discharging The Battery
It is connected to a low current switch conveniently located for the driver by a low current cable. The concern of long battery cables shorting to the chassis is all but gone. It operates as a latching relay, drawing NO current to keep it closed or open. This latching feature allows the Disconnect to operate without discharging the battery. To close the Disconnect, a positive voltage is applied to the unmarked terminal of the coil and the negative of the supply is connected to the “S” terminal, for a brief period. When the power is removed, the relay is latched in the “on” or closed position. Current can now flow through the large terminals. The Disconnect is ignition protected, so it can safely be mounted in a convenient place near the battery. It can be mounted in any orientation. It is immune to harsh shake and vibration found in the vehicle or marine environment. The Disconnect in a typical installation, is mounted near the vehicle battery to keep the length of the battery cables to a minimum. Keeping these wires short adds to the safety of the installation and helps minimize the cost. The wires to the Disconnect’s coil are run to a remote switch, usually located at a convenient location near an entry door. Additional switches can be wired to allow operation of the Disconnect from multiple locations, such as the front and rear of a vehicle. If required, Intellitec can provide a complete solution with disconnect, switch and harnessing to suit most applications.
Founded in 1994, Intellitec® has evolved from a small supplier of battery protection equipment to an internationally renowned manufacturer of electronic systems and other related products intended to solve your power problems. Intellitec’s product line consists of over 10,000 systems and parts used for power distribution, charging, switching, and controlling electrical systems in a wide variety of applications, including bus, truck, emergency service, leisure vehicles, and marine. Everything from batteries, battery chargers, monitors, and guards to inverters, isolation transformers, solar products, and much more, the company has the solution that meets your individual needs. Intellitec is proud to be ISO 9001 & 14001-2015 certified by ISOQAR and UKAS, and also holds accreditation by Vehicle Certification Agency for Conformity of Product (COP).
