Product Details
1000W 12V Pure Sine Inverter Charger with ETL Listed to UL 458 Standard (PICOGLF10W12V120V) by AIMS Power®. Here’s the AIMS Power 1000 Watt Pure Sine Low Frequency Inverter with built-in battery charger. This inverter charger is perfect for small-sized industrial applications that depend upon power being available even under heavy load. This heavy-duty inverter charger is ready to go wherever you need it to: off-grid home back up power, solar systems, business back-up power, campsites, tailgating parties or any recreational locations. Use this product to power your essential household appliances during a power outage emergency. This inverter is also great in a smaller RV or boat. If 1000 watts is not enough power, check out AIMS Power full line of low frequency inverter chargers available in 12, 24 & 48 volt versions.
Specifications:
| Continuous Output Power: 1000 Watts |
| Surge Rating: 3000 Watts (20 Seconds) |
| Output Waveform: Pure Sine/Same as input (Bypass Mode) |
| Nominal Efficiency: more 88% (Peak) |
| Line Mode Efficiency: more 95% |
| Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz |
| Typical Transfer Time: 10ms (Max) |
| Bypass Breaker – 20 amps |
| THD: less 10% DC |
| Ambient operating temperature: 14°F to 122°F (-10°C to 50°C) |
| Nominal Input Voltage: 12.0Vdc |
| Minimum Start Voltage: 10.0Vdc |
| Low Battery Alarm: 10.5Vdc-11.0Vdc |
| Low Battery Trip: 10.0Vdc-10.5Vdc |
| High Voltage Alarm: 16.0Vdc |
| Low Battery Voltage Restart: 13.3Vdc |
| Idle Consumption: less 12.5 watts |
| Charger Breaker 10 amps |
| Power Saver Mode Idle Consumption: less 7.5 wattsC |
| Output Voltage: Depends on battery Type |
| Charger Rate: 35A |
| Over Charge Protection Shutdown 15.7V |
| Selectable Charge Setting Dial |
| Adjustable Charge Current: off-20%-100% |
| Four Stage Smart Charger |
| 30 amp auotmatic transfer switch |
| 10 ms (max) |
| Unit Weight: 35 lbs. |
| Unit Size L x W x H: 14.1 x 8.74 x 7.10 inches |
Features:
- 1000 watt low frequency inverter
- 3000 watt surge for 20 seconds 300% surge capability
- Battery priority selector
- Terminal block
- GFCI outlet – 10 amps
- Marine coated and protected
- Multi stage smart charger 35 Amp for gel, AGM, lead and lithium LiFePO4
- Remote panel available
- Auto frequency
- 10msec typical transfer time
- Selectable 25W power save mode (hibernation)
- 7 battery type settings for charger
- Automatic transfer switch
This AIMS power inverter charger is capable of accepting any source of 120v AC power to charge batteries, including a gas or diesel generator or shore power at an RV park/truck stop. It will even accept power from an extension chord plugged into your wall outlet at home. This inverter charger is capable of a 3000 watt surge for 20 seconds and can run at 1000 watts continuously.
As an additional feature, this inverter is capable of being used worldwide by virtue of its auto frequency detection capabilities. It will run in any country that uses 120vac output. It works with type-A plugs or a direct 3-wire terminal connection. This inverter comes with a dual-plug GFCI outlet with a reset button. This inverter will never completely drain your batteries as it’s low-voltage shut-down keeps the voltage at either 10 volts or 10.5 volts depending on your selection.
With the battery priority mode, you can set your inverter to run directly off of a battery back-up system instead of a generator or tertiary source of AC Power. The inverter charger comes with a power saver mode that pulses every 30 seconds, attempting to detect a necessary load of 25 watts or more before it will turn on. Otherwise, the inverter will “sleep” and draw right around a half an amp per hour, saving you precious reserve power in your batteries until you need it.
An optional wired remote can be added for fast and easy operation if your inverter charger is mounted in a location that is inconvenient to get at. This allows the unit to be operated within the cab of a vehicle or from another location in the home or campsite.
