Product Details
120W Monocrystalline Solar Panel by AIMS Power®. The 120 Watt Monocrystalline Solar Panel from AIMS Power is a versatile performer constructed with high quality tempered glass and a stronger surface to protect from harsh weather conditions. The solar cells used in the panel are high transmission and the textured glass allows for more efficient solar power harvesting. The panel also includes a bypass diode that minimizes the power drop caused by shade. Easy to install using the pre-drilled holes on the aluminum outer frame. Perfect for home, vehicle and RV installations and large enough for industrial applications.
Specifications:
| Maximum Power (Watts): 120 watts |
| (Vmp): 18.5 volts operating voltage |
| (Imp): 6.49 amps operating current |
| (Voc): 22.2 volts open circuit voltage |
| (Isc): 7.14 amps |
| Solar Cell: 158.75mm x 105.83mm |
| Number of Cells (pcs): 9*4 = 36 |
| Front Glass Thickness (mm): 3.2 mm |
| Temperature Coefficients of Isc (%) °C: -0.048 |
| Temperature Coefficients of Voc (%) °C: -0.29 |
| Temperature Coefficients of Pm (%) °C: -0.37 |
| Temperature Range: -40°C to +80°C |
| Tolerance Wattage: 0-3 watts |
| Surface Maximum Load Capacity: 6000Pa snow and 3600Pa wind |
| Allowable Hail Load: 45mm at 30.7m/s |
| Bypass Diode Rating (A): 10 |
| Cell Efficiency (%): 19.84% |
| Module Efficiency (%): 17.30% |
| Warranty: 91.2% of 12 years, 80.6% of 25 years |
| Weight Per Panel (lbs): 17 lbs |
| Dimensions (inches): 40.15 x 26.75 x 1.37 |
Features:
- Monocrystalline efficient solar harvesting
- Strong surface for harsh environment
- Panels capable of 0 to +3 Watts over rated capacity
- Pre-drilled aluminum frame
- Tempered glass
- 25 Year limited warranty
California Residents
WARNING Cancer and Reproductive Harm.
Brand:
AIMS Power
Part Number:
PV120MONO
